TECHNICAL DATE FOR RUSIN DISPLAY MasterStone

SERIES MODEL Rusin Hidable 30.

-Display Panel
Technology Type: OLED
Panel Supplier: Samsung Display
Resolution: 1920×1080
Brightness: 400 cd/m²
Transparency: 80 %
Active Display Area: 344.2×193.6 mm
Contrast Ratio: 100 000:1
Viewing Angle: 178°/178°
Color Gamut: 100 % DCI-P3
Refresh Rate: 60 Hz
Color Depth: 8 bit + FRC
Response Time: 1 ms
Lifespan: 30 000 h
Glass Type: Gorilla Glass 3
Touch Method: Capacitive 10-point
-System & Mainboard (Optional)
Operating System: Android 12
Main Controller: Rockchip RK3566
Processor: Quad-core A55 1.8 GHz
Memory (RAM): 4 GB LPDDR4
Storage (ROM): 64 GB eMMC 5.1
Wi-Fi: 802.11 a/b/g/n/ac 2.4/5 GHz
Bluetooth: 5.0
-Interfaces & Connectivity (Optional)
Video Input: HDMI 2.0, DP 1.2, USB-C Alt Mode
USB Port: 2× USB-C 3.1, 1× USB-A 3.0
LAN Port: RJ45 GbE (Realtek RTL8153)
Serial Port: RS-232 (3-pin Phoenix)
Audio In/Out: 3.5 mm combo, 2× 2 W speaker
Power Input: 12 V/3 A DC jack
-Environmental & Power Specifications
Operating Temperature: 0 – 40 °C
Storage Temperature: -20 – 60 °C
Humidity Range: 10 % – 90 % RH non-condensing
Power Consumption: 12 W typ, 0.5 W standby
-Structure & Materials
Housing Material: Aluminum alloy 6061
Surface Treatment: Anodized silver, matte
Bonding Technology: OCA full lamination
Installation Method: VESA 75×75 mm / fold-back stand
Product Dimensions(mm): 355×225×8 mm
Net Weight (kg): 0.9 kg
-Navigation & Mobility
Navigation Method: 2-D LiDAR + visual fusion
LiDAR: 360° 10 m single-line
3D Camera: RealSense D430
Maximum Speed: 1.2 m/s
-Battery & Power
Battery Capacity: 10 000 mAh / 37 Wh
Operating Time: 6 h @ 50 % brightness
Charging Method: USB-C PD 45 W
Charging Time: 1.5 h (0-80 %)
Battery Lifespan: 800 cycles > 80 % capacity
Total Power: 25 W max
-Motion Control Parameters
Control Method: App + 2.4 GHz remote
Tilt Angle: -5° – +20°
Remote Control Distance: 10 m
Load Capacity: 5 kg static
-Packaging & Dimensions
Packaging Type 1: Retail color box
Package Dimensions (mm): 420×280×55 mm
Gross Weight (kg): 1.6 kg
Packaging Type 2: Flight case (10 pcs)
Package Dimensions (mm): 460×320×480 mm
Gross Weight (kg): 17 kg
-Accessories
Power Cable (with Region-specific Plug): 1.5 m US/EU/UK plug
Infrared Remote Control: 38 kHz, 2× AAA battery
Charger: 45 W USB-C PD GaN adapter
-Certifications & Standards
Safety Certifications: CE, FCC, RoHS, CB, UL
EMC & Safety Testing: EN 55032, EN 55035, IEC 62368-1
-Customization Options
Logo: Silk-print / laser engraving
Housing Color: Black / white / RAL custom
External Device Integration: NFC reader, 4G module, barcode scanner
